Overview

Movawall Type 200 is a sliding folding partition system of purpose made flat panels hinged together, to slide and fold to one or both sides within an alternative opening. Available primarily as a floor supported bottom roller system or as a top hung alternative option.

Panels have extra stability by means of a locking arrangement. Each alternate panel contains an espagnolette bolt mechanism operated via a detachable handle at a convenient height from the floor. The locking pin engages the floor rail and top track to ensure the panels close flat, flush and are rigid. The leading panel in the opening can be used as a full heigh pass door if required. Pass doors have flush pull handles and roller catch fitted; a lock can also be fitted.

Gallery
Features

Height

Up to 6,000mm high depending on weight

Panel Width

Up to 900mm

Sound Reduction

Up to Rw 52dB

Movawall systems offer the highest level of acoustic ratings available. Sound reduction is achieved using dense cladding, adding internal insulation materials within the panels and by using deep seated mechanically operated retractable seals set to a high sealing pressure applied by worm screw drive and deep interlocking vertical seals.

Special panel surface finishes can help maintain or improve the acoustic qualities of existing sound conditions. Panel faces can vary from acoustically absorbent slotted boards to improve sound absorption levels of a room to the use of soft fabrics to control levels of noise reverberation. Our walls are constantly being developed and confirmed by recognised testing authorities to achieve higher acoustic levels and greater client satisfaction.

Walls are measured in accordance with DIN EN 20 140-3. Please contact our technical department for any assistance required and further information.

Panel Thickness

80mm

Suspension Method

Floor supported with top guide or top hung

Operation Mode

Manual

Panel Type

Hinged

Seal Type

Fixed top and bottom sweep strips

Panel Construction

Aluminium frame

Panel Weight

Up to 42kg/m2

Pass Door Panels

Full height only single or double

Usage

Internal

Panel Edges

Exposed SAA or powder coated

Panel Finishes

• Laminate
• HP Laminate
• Veneer
• Fabric
• Whiteboard
• Magnetic whiteboard
• Inlayed fabric

Other Options

• Corner
• Junction
• Glazed cut outs

Drawings

All drawings are subject to change.

NBS Specification
Stacking Options

Endfold Single Unit

Centrefold Single Unit

Endfold Bi-Parting

Centrefold Bi-Parting
