Skywall system gives the flexibility of dividing a room into a separate space for any purpose at the touch of a button. The advantage over conventional systems are no obtrusive stacking arrangements. Simply press the button and partition sections glide gently downwards from the ceiling into position and form an attractive and effective partition between rooms. To retract, simply push the button and the Skywall’s unique design withdraws the system into a hidden compartment in the ceiling void, removing the system from view.


Skywall at Gazprom, London





Height Up to 4,000mm
Panel Width Upto 7,000mm
Sound Reduction Up to Rw 42dB

Common Sounds Sound Level (dB)
Threshold of Hearing 0
Whisper 13
Quiet Conversation 20
Private Office 30
Quiet Radio 40
Average Business Office 50
Limit for Quiet Office Environment 55
Normal Conversation 60
Limit for Normal Office Enviroment 70
Amplified Speech / Road Traffic / Loud Music 80
Limit for Factories 85
25 Piece Orchestra / Shouting Voice 1m 90
Continuous Exposure Dangerous to Hearing 95
Low Flying Aircraft / Noisy Plant 100
Hard Rock Band, Noisy Plant 115
Jet Aircraft Taking Off 20m Distance 120
Jack Hammer 1m Distance 125
Threshold of Pain 130

Panel Thickness 17/22/27mm
Show More
Suspension method Top hung
Operation Mode Fully electric
Panel Type Indivudual panel
Seal Type Electric
Panel Construction Aluminium frame
Usage Internal or external
Stacking Options Within ceiling void
Panel Finishes Single glazing/solid finish to clients spec



Stacking Options


Skywall Stacking
